1-14
Catalyst 3750-X and 3560-X Switch Software Configuration Guide
OL-25303-03
Chapter 1 Configuring SNMP
Configuring SNMP
Beginning in privileged EXEC mode, follow these steps to configure the switch to send traps or informs
to a host:
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
snmp-server engineID remote
ip-address engineid-string
Specify the engine ID for the remote host.
Step 3
snmp-server user username
groupname {remote host [udp-port
port]} {v1 [access access-list] | v2c
[access access-list] | v3 [encrypted]
[access access-list] [auth {md5 | sha}
auth-password]}
Configure an SNMP user to be associated with the remote host created in
Step 2.
Note You cannot configure a remote user for an address without first
configuring the engine ID for the remote host. Otherwise, you
receive an error message, and the command is not executed.
Step 4
snmp-server group groupname {v1 |
v2c | v3 {auth | noauth | priv}} [read
readview] [write writeview] [notify
notifyview] [access access-list]
Configure an SNMP group.
Step 5
snmp-server host host-addr
[informs | traps] [version {1 | 2c | 3
{auth | noauth | priv}}]
community-string [notification-type]
Specify the recipient of an SNMP trap operation.
• For host-addr, specify the name or Internet address of the host (the
targeted recipient).
• (Optional) Enter informs to send SNMP informs to the host.
• (Optional) Enter traps (the default) to send SNMP traps to the host.
• (Optional) Specify the SNMP version (1, 2c, or 3). SNMPv1 does
not support informs.
• (Optional) For Version 3, select authentication level auth, noauth, or
priv.
• For community-string, when version 1 or version 2c is specified,
enter the password-like community string sent with the notification
operation. When version 3 is specified, enter the SNMPv3 username.
Note The @ symbol is used for delimiting the context information.
Avoid using the @ symbol as part of the SNMP community string
when configuring this command.
• (Optional) For notification-type, use the keywords listed in Table 1-5
on page 1-12. If no type is specified, all notifications are sent.
Step 6
snmp-server enable traps
notification-types
Enable the switch to send traps or informs and specify the type of
notifications to be sent. For a list of notification types, see Table 1-5 on
page 1-12, or enter snmp-server enable traps ?
To enable multiple types of traps, you must enter a separate snmp-server
enable traps command for each trap type.
Note When you configure a trap by using the notification type
port-security, configure the port security trap first, and then
configure the port security trap rate:
• snmp-server enable traps port-security
• snmp-server enable traps port-security trap-rate rate
