1-26
Catalyst 3750-X and 3560-X Switch Software Configuration Guide
OL-25303-03
Chapter 1 Configuring QoS
Configuring Auto-QoS
• A switch is enabled with QoS, these guidelines take effect:
– If you configure the interface for conditional trust on a voice device, only the legacy auto-QoS
VoIP configuration is generated.
– If you configure the interface for conditional trust on a video device, the enhanced auto-QoS
configuration is generated.
– If you configure the interface with classification or conditional trust based on the new interface
auto-QoS commands, enhanced auto-QoS configuration is generated.
• Auto-QoS migration happens after a new device is connected when the auto qos srnd4 global
configuration command is enabled.
Note If an interface previously configured with legacy auto-QoS migrates to enhanced auto-QoS, voice
commands and configuration are updated to match the new global QoS commands.
Auto-QoS configuration migration from enhanced auto-QoS to legacy auto-QoS can occur only when
you disable all existing auto-QoS configurations from the interface.
Global Auto-QoS Configuration
Table 1-5 Generated Auto-QoS Configuration
Description Automatically Generated Command {voip}
Enhanced Automatically Generated
Command{Video|Trust|Classify}
The switch automatically enables
standard QoS and configures the
CoS-to-DSCP map (maps CoS
values in incoming packets to a
DSCP value).
Switch(config)# mls qos
Switch(config)# mls qos map cos-dscp
0 8 16 26 32 46 48 56
Switch(config)# mls qos
Switch(config)# mls qos map cos-dscp 0
8 16 24 32 46 48 56
The switch automatically maps
CoS values to an ingress queue
and to a threshold ID.
Switch(config)# no mls qos srr-queue
input cos-map
Switch(config)# mls qos srr-queue
input cos-map queue 1 threshold 2 1
Switch(config)# mls qos srr-queue
input cos-map queue 1 threshold 3 0
Switch(config)# mls qos srr-queue
input cos-map queue 2 threshold 1 2
Switch(config)# mls qos srr-queue
input cos-map queue 2 threshold 2 4 6
7
Switch(config)# mls qos srr-queue
input cos-map queue 2 threshold 3 3 5
Switch(config)# no mls qos srr-queue
input cos-map
Switch(config)# mls qos srr-queue
input cos-map queue 1 threshold 2 3
Switch(config)# mls qos srr-queue
input cos-map queue 1 threshold 3 6 7
Switch(config)# mls qos srr-queue
input cos-map queue 2 threshold 1 4

Cisco Catalyst 3560-X Specifications

General

Enclosure Type	Rack-mountable - 1U
Subtype	Gigabit Ethernet
Ports	48 x 10/100/1000 + 4 x SFP
Flash Memory	64 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Operating System	Cisco IOS
Device Type	Switch
Performance	Switching capacity: 128 Gbps
Jumbo Frame Support	Yes
Routing Protocol	RIP-1, RIP-2, EIGRP
Remote Management Protocol	SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, HTTP, HTTPS
Features	DHCP support, VLAN support, QoS, IPv6 support, Syslog
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad, IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.3at
Stacking	Stackable
Security Features	SSH, RADIUS, TACACS+
Management	CLI
Dimensions (H x W x D)	17.5 in
Operating Temperature	32 to 113 °F (0 to 45 °C)
Humidity	10 - 95% (non-condensing)
