Cisco ONS 15454 Troubleshoot Manual

2-113
Cisco ONS 15454 Troubleshooting Guide, R8.5
November 2009
Chapter 2 Alarm Troubleshooting
2.7.135 FORCED-REQ-SPAN
Step 2 If the condition does not clear, log into the Technical Support Website at
http://www.cisco.com/techsupport for more information or call Cisco TAC 1 800 553-2447.
2.7.135 FORCED-REQ-SPAN
Default Severity: Not Alarmed (NA), Non-Service-Affecting (NSA)
SONET Logical Object: EC1, OCN
DWDM Logical Objects: 2R, ESCON, FC, GE, ISC, TRUNK
The Force Switch Request Span condition can apply to optical trunk cards in two-fiber or four-fiber
BLSRs when the Force Span command is applied to a BLSR SPAN to force traffic from working to
protect or from protect to working. This condition appears on the network view Alarms, Conditions, and
History tabs. The port where the FORCE SPAN command was applied is marked with an “F” on the
network view detailed circuit map.
FORCED-REQ can be raised in 1+1 facility protection groups. If traffic is present on a working port and
you use the FORCE command to prevent it from switching to the protect port (indicated by “FORCED
TO WORKING”), FORCED-REQ-SPAN indicates this force switch. In this case, the force is affecting
not only the facility, but the span.
Clear the FORCED-REQ-SPAN Condition
Step 1 Complete the “Clear a BLSR External Switching Command” procedure on page 2-269.
Step 2 If the condition does not clear, log into the Technical Support Website at
http://www.cisco.com/techsupport for more information or call Cisco TAC 1 800 553-2447.
2.7.136 FP-LINK-LOSS
Default Severity: Minor (MN), Non-Service-Affecting (NSA)
SONET Logical Object: EQPT
The Front Port Link Loss condition occurs when a LAN cable is not connected to the front port of the
TCC2/TCC2P card.
Clear the FP-LINK-LOSS Condition
Step 1 Connect a LAN cable to the front port of the TCC2/TCC2P card.
Step 2 If the condition does not clear, log into the Technical Support Website at
http://www.cisco.com/techsupport for more information or call Cisco TAC 1 800 553-2447.

Cisco ONS 15454 Specifications

General

Form Factor	Rack-mountable
Management	Cisco Transport Controller (CTC), TL1, SNMP
Protocols	SONET/SDH, Ethernet, OTN
Power Supply	Redundant AC or DC power supplies
Slots	17
Supported Interfaces	OC-3/STM-1 to OC-192/STM-64, 10/100/1000 Ethernet, 10G Ethernet
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Humidity	5% to 95% non-condensing
Weight	Approximately 75 lb (34 kg)
Interfaces/Ports	Ethernet, SONET/SDH, Fibre Channel
