Chapter 2 Alarm Troubleshooting
2.7.323 PRC-DUPID
3. Specify proper payload value in the Media Type field.
4. Click Apply.
For the CE-MR-10 and FC_MR-10 card, the alarm can also be cleared using TL1 commands. For
detailed instructions, refer to the Cisco ONS 15454, Cisco ONS 15600, and Cisco ONS 15310-MA
SONET TL1 Command Guide.
For the ML-MR-10 card, the alarm can be cleared through Cisco IOS commands. For detailed
instructions, refer to the Cisco ONS 15454 and Cisco ONS 15454 SDH Ethernet Card Software Feature
and Configuration Guide.
If the alarm does not clear, log into the Cisco Technical Support Website at
http://www.cisco.com/techsupport for more information or call Cisco TAC (1 800 553-2447) to report a
Service-Affecting (SA) problem.
2.7.323 PRC-DUPID
Default Severity: Major (MJ), Service-Affecting (SA)
SONET Logical Object: OCN
The Procedural Error Duplicate Node ID alarm indicates that two identical node IDs exist in the same
ring. The ONS 15454 requires each node in the ring to have a unique node ID.
Clear the PRC-DUPID Alarm
Step 1 Log into a node on the ring.
Step 2 Find the node ID by completing the “Identify a BLSR Ring Name or Node ID Number” procedure on
page 2-261.
Step 3 Repeat Step 2 for all the nodes on the ring.
Step 4 If two nodes have an identical node ID number, complete the “Change a BLSR Node ID Number”
procedure on page 2-261 so that each node ID is unique.
Step 5 If the alarm does not clear, log into the Technical Support Website at http://www.cisco.com/techsupport
for more information or call Cisco TAC 1 800 553-2447 in order to report a Service-Affecting (SA)
problem.
2.7.324 PROTNA
Default Severity: Minor (MN), Non-Service-Affecting (NSA)
SONET Logical Object: EQPT
The Protection Unit Not Available alarm is caused by an OOS protection card when a TCC2/TCC2P or
XC10G card that has been provisioned as part of a protection group is not available. Unavailable
protection can occur when a card is reset, but the alarm clears as soon as the card is back in service. The
alarm clears if the device or facility is brought back in service.
