Chapter 2 Alarm Troubleshooting
2.4 Alarm List by Logical Object Type
2.4 Alarm List by Logical Object Type
Table 2-8 lists all ONS 15454 alarms and logical objects as they are given in the system alarm profile.
The list entries are organized by logical object name and then by alarm or condition name. Where
appropriate, the alarm entries also contain troubleshooting procedures.
Note In a mixed network containing different types of nodes (such as ONS 15310-CL, ONS 15454, and
ONS 15600), the initially displayed alarm list in the Provisioning > Alarm Profiles > Alarm Profile
Editor tab lists all conditions that are applicable to all nodes in the network. However, when you load
the default severity profile from a node, only applicable alarms will display severity levels.
Nonapplicable alarms can display “use default” or “unset.”
Note In some cases this list does not follow alphabetical order, but it does reflect the order shown in CTC.
PPM Pluggable port module (PPM), referring to OC192-XFP, MXP, TXP, and MRC
cards. For more information about PPM alarms, refer to the “Alarm
Troubleshooting” chapter in the Cisco ONS 15454 DWDM Troubleshooting Guide.
PWR Power equipment.
RPRIF Interface for Resilient Packet Ring technology as defined in IEEE 802.17b. Also
called RPR-IEEE.
SHELF The shelf assembly. For more information about most of the alarms on this object,
refer to the “Alarm Troubleshooting” chapter of the Cisco ONS 15454 DWDM
Troubleshooting Guide.
STSMON STS alarm detection at the monitor point (upstream from the cross-connect).
STSTRM STS alarm detection at termination (downstream from the cross-connect).
TLINK Traffic engineering (TE) link correlation.
TRUNK The optical or DWDM card carrying the high-speed signal; referring to MXP or
TXP cards. For more information about TRUNK alarms, refer to the “Alarm
Troubleshooting” chapter in the Cisco ONS 15454 DWDM Troubleshooting Guide.
VCG A virtual concatenation group of VTs.
VT-MON VT1 alarm detection at the monitor point (upstream from the cross-connect).
VT-TERM VT1 alarm detection at termination (downstream from the cross-connect).
Table 2-7 Alarm Logical Object Type Definitions (continued)
Logical Object Definition
Table 2-8 Alarm List by Logical Object in Alarm Profile
2R: ALS (NA) FC: AS-CMD (NA) OCN: MANUAL-REQ-RING (NA)
2R: AS-CMD (NA) FC: AS-MT (NA) OCN: MANUAL-REQ-SPAN (NA)
2R: AS-MT (NA) FC: CARLOSS (MJ) OCN: PRC-DUPID (MJ)
2R: FAILTOSW (NA) FC: FAILTOSW (NA) OCN: RFI-L (NR)
