2.7.235 LPBKDS3FEAC
Clear the LPBKCRS Condition
Step 1 To remove the loopback cross-connect condition, double-click the optical card in CTC to open the card
view.
Step 2 Complete the “Clear an OC-N Card Cross-Connect (XC) Loopback Circuit” procedure on page 2-276.
Step 3 If the condition does not clear, log into the Technical Support Website at
http://www.cisco.com/techsupport for more information or call Cisco TAC 1 800 553-2447.
2.7.235 LPBKDS3FEAC
Default Severity: Not Alarmed (NA), Non-Service-Affecting (NSA)
SONET Logical Object: DS3
A Loopback Due to FEAC Command DS-3 condition occurs when a DS3XM-6, DS3XM-12, DS3-12E,
or DS3/EC1-48 port loopback signal is received in C-bit framing mode from the far-end node because
of an FEAC command. An FEAC command is often used with loopbacks. LPBKDS3FEAC is only
reported by these DS cards. DS3XM-6, DS3XM-12, and DS3/EC1-48 cards generate and report FEAC
alarms or conditions, but a DS3-12E card only reports FEAC alarms or conditions.
Caution CTC permits loopbacks on an in-service (IS) circuit. Loopbacks are Service-Affecting (SA).
Note LPBKDS3FEAC is an informational condition and does not require troubleshooting.
Clear the LPBKDS3FEAC Condition
Step 1 In node view, double-click the DS-3 card to open the card view.
Step 2 Click the Maintenance > DS3 tabs.
Step 3 Click the cell for the port in the Send Code column and click No Code from the drop-down list.
Step 4 If the condition does not clear, log into the Technical Support Website at
http://www.cisco.com/techsupport for more information or call Cisco TAC 1 800 553-2447.
2.7.236 LPBKDS3FEAC-CMD
Default Severity: Not Alarmed (NA), Non-Service-Affecting (NSA)
SONET Logical Object: DS3
The DS-3 Loopback Command Sent To Far End condition occurs on the near-end node when you send
a DS-3 FEAC loopback on DS3XM-6, DS3XM-12, or DS3/EC1-48 cards. For more information about
FEAC loopbacks, see the “1.3 Troubleshooting DS3XM-6 or DS3XM-12 Card Electrical Paths With
FEAC Loopbacks” section on page 1-45.
