1-30
Cisco ONS 15454 Troubleshooting Guide, R8.5
November 2009
Chapter 1 General Troubleshooting
1.2.5 Perform a Facility Loopback on a Destination-Node Electrical Port (East to West)
Step 4 For the DS3 tab, choose OOS,MT from the Admin State column for the port being tested. If this is a
multiport card, select the appropriate row for the port being tested. For the DS1 tab, no state selection is
necessary unless the DS-1 is in service. The loopback/send code cannot be selected for a DS-1 if the
derived state is OOS,DSBLD.
Step 5 Choose Facility from the Loopback Type column for the port being tested. If this is a multiport card,
select the appropriate row for the port being tested.
Step 6 Click Apply.
Step 7 Click Yes in the confirmation dialog box.
Note It is normal for the “LPBKFACILITY (DS1, DS3)” condition on page 2-169 to appear during
loopback setup. The condition clears when you remove the loopback.
Step 8 Complete the “Test and Clear the DS3E or DS3XM Port Facility Loopback Circuit” procedure on
page 1-30.
Test and Clear the DS3E or DS3XM Port Facility Loopback Circuit
Step 1 If the test set is not already sending traffic, send test traffic on the loopback circuit.
Step 2 Examine the traffic received by the test set. Look for errors or any other signal information that the test
set is capable of indicating.
Step 3 If the test set indicates a good circuit, no further testing is necessary with the facility loopback.
Double-click the card to open the card view.
Step 4 For any of these cards, click the Maintenance > DS3 tabs.
Note The DS-3 Admin State is the basis of the DS-1 Derived State.
Step 5 Choose None from the Loopback Type column for the port being tested.
Step 6 Choose the appropriate state (IS; OOS,DSBLD; OOS,MT; IS,AINS) from the Admin State column for
the port being tested.
Step 7 Click Apply.
Step 8 Click Yes in the confirmation dialog box.
Step 9 Complete the “Test the Electrical Cabling” procedure on page 1-30.
Test the Electrical Cabling
Step 1 Replace the suspected bad cabling (from the test set to the DSx panel or the EIA ports) with known-good
cable. For instructions, refer to the “Install Cards and Fiber-Optic Cable” chapter in the
Cisco ONS 15454 Procedure Guide.
