2-110
Cisco ONS 15454 Troubleshooting Guide, R8.5
November 2009
Chapter 2 Alarm Troubleshooting
2.7.129 FE-MANWKSWPR-RING
The Far End Manual Switch Back to Working—Span condition occurs when a far-end span with a
Manual switch reverts to working.
Note WKSWBK-type conditions such as FE-MANWKSWBK-SPAN apply only to nonrevertive spans.
Clear the FE-MANWKSWBK-SPAN Condition
Step 1 To troubleshoot the FE condition, determine which node and card link directly to the card reporting the
FE condition. For example, an FE condition on a card in Slot 12 of Node 1 could relate to a main alarm
from a card in Slot 6 of Node 2.
Step 2 Log into the node that links directly to the card reporting the FE condition.
Step 3 Complete the “Clear a BLSR External Switching Command” procedure on page 2-269.
Step 4 If the condition does not clear, log into the Technical Support Website at
http://www.cisco.com/techsupport for more information or call Cisco TAC 1 800 553-2447.
2.7.129 FE-MANWKSWPR-RING
Default Severity: Not Alarmed (NA), Non-Service-Affecting (NSA)
SONET Logical Object: EC1, OCN
The Far End Ring Manual Switch of Working Facility to Protect condition occurs when a BLSR working
ring is switched from working to protect at a far-end node using the Manual Ring command.
Clear the FE-MANWKSWPR-RING Condition
Step 1 To troubleshoot an FE condition, determine which node and card link directly to the card reporting the
FE alarm. For example, an FE-AIS condition from the OC-48 card in Slot 12 of Node 1 could link to the
main AIS condition from an OC-48 card in Slot 6 of Node 2.
Step 2 Log into the node that links directly to the card reporting the FE condition.
Step 3 Complete the “Clear a BLSR External Switching Command” procedure on page 2-269.
Step 4 If the condition does not clear, log into the Technical Support Website at
http://www.cisco.com/techsupport for more information or call Cisco TAC 1 800 553-2447.
2.7.130 FE-MANWKSWPR-SPAN
Default Severity: Not Alarmed (NA), Non-Service-Affecting (NSA)
SONET Logical Object: OCN
