2.7.402 SWMTXMOD-WORK
Step 2 Verify that the reset is complete and error-free and that no new related alarms appear in CTC. A green
ACT/SBY LED indicates an active card. An amber ACT/SBY LED indicates a standby card.
Step 3 If the alarm does not clear, complete the “Remove and Reinsert (Reseat) Any Card” procedure on
page 2-273 for the Slot 10 cross-connect card.
Step 4 Complete the “Side Switch the Active and Standby Cross-Connect Cards” procedure on page 2-271.
Note After the active cross-connect card goes into standby mode, the original standby slot becomes
active. The former standby card ACT/SBY LED becomes green.
Step 5 If the alarm does not clear, log into the Technical Support Website at http://www.cisco.com/techsupport
for more information or call Cisco TAC 1 800 553-2447 in order to report a Service-Affecting (SA)
problem.
2.7.402 SWMTXMOD-WORK
Default Severity: Critical (CR), Service-Affecting (SA)
SONET Logical Object: EQPT
The Switching Matrix Module Failure on Working Slot alarm is raised by the Slot 8 cross connect card
if this card is active (ACT). Any kind of cross-connect card can raise this alarm. (Two exceptions are
given in the following paragraph.) SWMTXMOD-WORK occurs when a logic component internal to the
Slot 8 cross connect is OOF with a traffic card in the system. In this case, the alarm is raised against the
traffic card slot.
The XC-VXC-10G card can raise this alarm (in Slot 8) whether it is ACT or standby (SBY). The XCVT
card can raise SWMTXMOD-WORK against itself if the cross-connect card is OOF with a second logic
component on the same cross connect card.
Clear the SWMTXMOD-WORK Alarm
Step 1 Complete the “Reset a Traffic Card in CTC” procedure on page 2-270 for the Slot 8 card. For LED
behavior, see the “2.8.2 Typical Traffic Card LED Activity During Reset” section on page 2-260.
Step 2 Verify that the reset is complete and error-free and that no new related alarms appear in CTC. A green
ACT/SBY LED indicates an active card. An amber ACT/SBY LED indicates a standby card.
Step 3 If the alarm does not clear, complete the “Remove and Reinsert (Reseat) Any Card” procedure on
page 2-273 for the Slot 8 cross-connect card.
Step 4 Complete the “Side Switch the Active and Standby Cross-Connect Cards” procedure on page 2-271.
Note After the active cross-connect card goes into standby mode, the original standby slot becomes
active. The former standby card ACT/SBY LED becomes green.
