Configuring LED Patterns
Cisco Small Business SPA300 Series, SPA500 Series, and WIP310 IP Phone Administration Guide 227
9
The table shows the MWI LED pattern for the SPA301 phone in SIP mode:
The table shows the MWI LED pattern for SPA IP phones in SCCP mode:
The table shows the MWI LED pattern/status indicator for the SPA301 phone in
SCCP mode:
Description LED Pattern
Temporary Ethernet link lost Heart-beat blink red
Permanent Ethernet link lost (resulting in a reboot
when link is detected again) ) amber
Heart-beat blink amber
Firmware downloading Slow blink amber
Firmware upgrading Fast blink amber
Phone registration failed Solid amber
Call on hold Slow blink red
No response to a paging message Fast blink green
Description LED Pattern
Incoming call Fast blink amber
Call on hold Slow blink green
Call active (off-hook) Solid green
Description LED Pattern
Temporary Ethernet link lost Heart-beat blink red
Permanent Ethernet link lost (resulting in a reboot
when link is detected again)
Heart-beat blink amber
