2 Installation of „CncPOD“
The following description of the installation procedure assumes that the machine and the rest of the
electronics (PC and Zero3 control, for example) are already operational.
Power supply
The CncPod requires a 5V power supply with USB port for power supply. To connect the power
supply to the CncPOD, a USB cable with a mini-USB connector is used. Please always use an extra
power adapter, and do not connect the CncPOD to the PC with a USB cable. Although this also
works for test purposes, the galvanic isolation of the network connection would be ineffective,
making the controller unnecessarily susceptible to electromagnetic interference. The USB port is for
power only. A data transfer with USB is not provided.
LPT-Ports
A 25-pin SUB-D cable connects the CncPod to the machine's control electronics (Zero3 or Raptor
cabinet, for example). At port 1, the step signals of the first 4 axes and the switch and relay signals
are available. At port 2, extensions such as Tool changer, frequency converter or a laser module can
be connected.
