Chapter2 Monitor Assembly
Caution
For normal work of the monitor, before use please read this chapter and the Patient
Safety chapter and assemble in accordance with the requirements.
2.1 Open Package and Check
Carefully pick up the monitor and accessories from the package box, and properly keep the
package materials for future transport or storage. Please check the accessories with the package
checklist.
Check whether there is any mechanical damage;
Check all the exposed cables and plug in some accessories for test.
Any problems should be immediately raised to the Sales Department of our Company or our
agents.
2.2 Connect with AC Cable
Procedures to connect with AC power cables:
Make sure the AC supply complies with the following specification: 100-250VAC，50/60Hz
Use the power cables provided with the monitor together. Plug in the power cable into power
supply interface of the monitor, while insert the other end of this cable to a 3-phase earthing power
socket.
Caution
Connect the power cable with the sockets special for hospital use.
If deemed necessary, connect with an equal-potential earthing cable. Refer to the equal-potential
earthing part in the Patient Safety chapter.
Caution
In case configured with a battery, the equipment after transport or storage must have
the battery taken for charging. Thus in case of direct booting without connection with
AC power supply, the equipment may not work properly due to insufficient power. With
AC power supply connected, the battery will be charged no matter the monitor is
