63
○
3 Filtering Mode: The cleaner or precise waveform can be obtained through filtering.
There are three filtering modes for option. The unfiltered ECG waveform is shown in
the diagnostic mode; the monitoring mode will possibly lead to the artifact filtering;
the operation mode used in the surgery can reduce the artifact and interference from
the electrosurgery unit. The filtering mode can be used in two channels and displayed
on the upper part of the first ECG waveform.
Warning
Only in the diagnostic mode can the system provide the real signal that has not been
treated. In the filtering modes such as “Monitoring” and “Operation”, the ECG
waveform will abnormally occur to the different extents. At this time the system can
only provide the basic ECG status, and will produce greater influence on the analysis
result of ST Segment. The analysis result of ARR may partially be affected in the
operating mode, so it is suggested that efforts are made to monitor patients in the
diagnostic mode when the interference is small.
○
4 the waveform of the ECG lead
○
5 The Name of 2nd-ECG Waveform Gain: for details, please refer to
○
1
Caution
The detected pacing signal displays on the upper part of the ECG waveform in the
waveform area, which is expressed as “
”.
11.5 ECG Menu
11.5.1 ECG setting in parameter area
Use turn knob and move cursor on the main screen to the ECG hot keys in the parameter area,
then press the knob to pop up the ECG Setting menu:
To Next Page
