interval for TREND data.
6.2.2 Observe earlier or later TREND curves
Press “ or ” button or rotate the knob clockwise or anticlockwise so as to observe later or
earlier TREND curves.
6.2.3 Observe TREND data of various parameters
Press “ or ” button and select one group of parameters out of 6 available groups.
6.2.4 Operation sample
To observe a NIBP TREND Figure:
Press the TREND button on the control panel to pop up the Main menu;
Select the TREND Figure Review option in the menu;
1. Press “
or ” button or rotate the knob to select the NIBP （S/D/M ）DATE;
2.
Select the resolution: click the left item and select the expected data interval;
3.
Press “
or ” button or rotate the knob, while observing NIBP TREND data over various
time;
4.
Press “
” to exit observation on TREND table.
6.3 NIBP RECALL
The monitor can record the latest 2000 NIBP datas. After select the NIBP RECALL in MAIN
MENU, the window will display 10 groups of NIBP records as follows:
