6.1.6 Operation sample
Observe the NIBP TREND diagram within the latest 1 hour:
Press the TREND button on the control panel to pop up the Main menu;
Select the TREND Diagram Review option in the menu;
1. Select the parameter: rotate the knob in the Parameter Selection item until “NIBP” is
shown in the dropdown box;
2. Select 1 or 5 seconds in the Resolution item;
3. Press the “
or ” button or rotate the knob, while observing changes in the
TREND diagram time and TREND curves;
4. Stop at the period to be carefully observed; in case the vertical axis is out of proper size,
for example, some TREND values exceed the highest value of the current vertical
axis, select “Adjust amplitude” to adjust;
5. If users want to know the measured value at certain time, just select “move cursor” and
move the cursor to where they wants, then time will be displayed above the curve and
measured values below the curve;
6. If users need output the TREND diagrams to the recorder, just select the “record” button
so as to let the recorder output NIBP TREND of the current review window;
7. Press “
” to exit observation on TREND diagram.
6.2 TREND TABLE (TREND Figure)
TREND Figure data over the previous 120 hours can be displayed in the following resolutions: 1
minute, 5 minutes, 10 minutes, 30 minutes and 60 minutes.
Select “TREND TABLE” under the “Main Menu” to pop up the following TREND figure:
