Chapter5 Recording
In the Main Menu, select the “MONITOR SETUP”, then to RECORD menu
5.1 General Information on the Recorder
The recorder used with this monitor is a heat-sensitive array recorder, with print width of 50mm.
Recorder capability
1. Outputted waveforms run at 25mm /sec or 50mm / sec
2. Maximally record two waveforms
3. Grid output function is optional
4. English output
5. Real-time record time and waveforms are selected by users through menus
6. Automatic record interval is selected by users through menus, while waveforms are
identical to real-time records
5.2 Record Type
This monitor generates slip records of the following types:
Real-time continuous record;
Real-time 3, 5, 8-second record;
Automatic alarm record;
5.2.1 Real-time record
Start recording waveforms from the moment you press the button.
Real-time continuous record for 8-second defaulted by machine system (normally only for two
waveforms) or set by users through menu. Please refer to relevant chapters for details.
Caution
During output process, the next parameter alarming output will be outputted after
completion of the current output.
