xStack
®
DGS-3600 Series Layer 3 Managed Gigabit Ethernet Switch
GVRP Settings
This window allows you to determine whether the Switch will share its VLAN configuration information with other GARP
VLAN Registration Protocol (GVRP) enabled switches. In addition, Ingress Checking can be used to limit traffic by filtering
incoming packets whose VID does not match the PVID of the port. Results can be seen in the table under the configuration
settings, as seen below.
To view this window, click L2 Features > VLAN > GVRP Settings, as shown below:
Figure 3- 8. GVRP Settings window
The following parameters may be configured.
Parameter Description
Unit
Select the unit to configure.
From/To
These two fields allow you to specify the range of ports that will be included in the Port-based VLAN
that you are creating using the 802.1Q Port Settings window.
97
