xStack
®
DGS-3600 Series Layer 3 Managed Gigabit Ethernet Switch
MLD Snooping Group
The following window allows the user to view MLD Snooping Groups present on the Switch. MLD Snooping is an IPv6 function
comparable to IGMP Snooping for IPv4. The user may browse this table by VLAN Name present in the switch by entering that
VLAN Name in the empty field shown below, and clicking the Find button.
To view this window, click Monitoring > MLD Snooping Group, as shown below:
Figure 8- 35. MLD Snooping Group Table window
The following field can be viewed:
Parameter Description
VID
The VLAN ID of theVLAN.
VLAN Name
The VLAN to which the member port belongs.
Source
Displays the status of the source filtering, which is the ability for a system to report the interest in
receiving packets from specific source addresses or sent to a particular multicast address.
Group
The IP address of the MLD multicast group.
Member Ports
The ports that are members of the multicast group.
Filter Mode
The filter mode will display Include or Exclude depending on whether or not the multicast-
address had been configured to include or exclude the filter.
NOTE: To configure MLD snooping for the Switch, go to the L2 Features folder and
select MLD Snooping. Configuration and other information concerning MLD snooping
may be found in Section 6 of this manual under MLD Snooping.
448
