xStack
®
DGS-3600 Series Layer 3 Managed Gigabit Ethernet Switch
Port Utilization
This window displays the percentage of the total available bandwidth being used on the port.
To view the port utilization, click Monitoring > Port Utilization, as shown below:
Figure 8- 7. Port Utilization window
Select a Port number from its drop-down menu and click Apply to display the Port Utilization for a particular port. The following
fields can be set:
Parameter Description
Time Interval
Select the desired setting between 1s and 60s, where "s" stands for seconds. The default
value is one second.
Record Number
Select number of times the Switch will be polled between 20 and 200. The default value is
200.
Show/Hide
Check whether to display Port Utilization.
Click Clear to refresh the graph. Click Apply to set changes implemented.
419
