xStack
®
DGS-3600 Series Layer 3 Managed Gigabit Ethernet Switch
Type
Select to enter the information in IP Address and/or User Name fields. Available options are IP
Address, User Name and Both.
IP Address
Enter the IP address of the global RCP server.
User Name
Enter the remote user name.
Click Apply to implement the changes.
RCP Services
This window is use to configure the services that provided by the RCP server.
To view this window, click Administration > RCP > RCP Services, as shown below:
Figure 2- 41. RCP Services window
The following parameters can be configured:
Parameter Description
Operation
Use the pull-down menu to select the method for copying files. Options are Download Firmware,
Download Configuration, Upload Configuration, Upload Log, and Upload Attack Log.
RCP Server IPv4
Address
Enter the IP address of the RCP Server.
User Name
Enter the remote user name on the RCP server.
Local File Name
Enter the file name in the field. Tick the Increment, and the existing configuration will not be
cleared before applying the new configuration.
Unit Number
Select the switch in the switch stack from which, or to which to upload or download files. Tick the
ALL check box to denote all switches in the switch stack.
Image ID
Use the pull-down menu to select the Image file ID.
Configuration ID
Use the pull-down menu to select the configuration file ID.
Filter
Use to filter configuration data.related to upload configuration.
Click Apply to implement the changes.
43
