xStack
®
DGS-3600 Series Layer 3 Managed Gigabit Ethernet Switch
IGMP Snooping Forwarding
The IGMP Snooping Forwarding table displays the current multicast traffic that the device has received and which ports it should
forward.
To view this window, click Monitoring > IGMP Snooping Forwarding, as shown below:
Figure 8- 38. IGMP Snooping Forwarding Table window
The user may search the IGMP Snooping Forwarding Table by VLAN Name by entering a VLAN name and then clicking
Search.
The following field can be viewed:
Parameter Description
VLAN Name
The VLAN Name where multicast packets are being received.
Source IP
The Source IP address that is sending multicast packets.
Multicast Group
The Multicast IP address located in the multicast packet.
Port Member
These are the ports where the IP multicast packets are being forwarded.
451
