xStack
®
DGS-3600 Series Layer 3 Managed Gigabit Ethernet Switch
BGP Summary Table
To view this read-only window, click L3 Features > BGP > BGP Summary Tables, as shown below:
Figure 4- 147. BGP Summary Information window
The BGP summary information parameters are described below:
Parameter Description
BGP Summary Information
BGP Router
Identifier
This field is used to display the local BGP router identifier previously configured.
Local AS Number
This field is used to display the local AS Number previously configured.
Dampening
This field is used to display the BGP dampending state: enabled or disabled.
BGP AS Path Entries
This field is used to display the total number of BGP AS path entries.
BGP Community
Entries
This field is used to display the total number of BGP community entries.
BGP Summary Table
Neighbor
This field is used to display the IP address of the BGP neighbor.
Version
This field is used to display the BGP version of the BGP neighbor.
AS Number
This field is used to display the remote AS number of the BGP neighbor.
MsgRcvd
This field is used to display the number of all BGP packets received from the BGP neighbor.
MsgSent
This field is used to display the number of all BGP packets sent to the BGP neighbor.
Up/Down
This field is used to display the connecting state or connecting time of the BGP neighbor.
State/PfxRcd
This field is used to display the establishing state or the number of BGP prefixes received
from the BGP neighbor.
288
