xStack
®
DGS-3600 Series Layer 3 Managed Gigabit Ethernet Switch
System Log
The System log on the Switch can record event information in its own logs, to designated SNMP trap receiving stations, and to the
PC connected to the console manager. The System Log folder contains two main windows System Log Host and System Log
Save Mode Settings.
System Log Host
The Switch can send Syslog messages to up to four designated servers using the System Log Server.
To view this window, click Administration > System Log > System Log Host, as shown below:
Figure 2- 24. System Log Host window
The parameters configured for adding and editing System Log Server settings are the same. See the table below for a description.
Figure 2- 25. System Log Server Settings – Add window
To set the System Log Server configuration, click Apply. To delete an entry from the System Log Host window, click the
corresponding
under the Delete heading of the entry to delete. To return to the System Log Host window, click the Show All
System Log Servers link.
The following parameters can be set:
Parameter Description
Index (1-4)
Syslog server settings index (1 to 4).
Server IP
The IP address of the Syslog server.
Severity
This drop-down menu allows you to select the level of messages that will be sent. The options
are Emergency, Alert, Critical, Error, Warning, Notice, Informational, Debug, All, and Level.
27
