xStack
®
DGS-3600 Series Layer 3 Managed Gigabit Ethernet Switch
DHCP/BOOTP Relay Interface Settings
This window allows the user to set up a server, by IP address, for relaying DHCP/ BOOTP information to the Switch. The user
may enter a previously configured IP interface on the Switch that will be connected directly to the DHCP/BOOTP client using the
following window. Properly configured settings will be displayed in the table at the bottom of the following window, once the
user clicks the Add button under the Apply heading. The user may add up to four server IPs per IP interface on the Switch.
To view this window, click Administration > DHCP/BOOTP Relay > DHCP/BOOTP Relay Interface Settings, as shown
below:
Figure 2- 49. DHCP/BOOTP Relay Interface Settings window
The following parameters may be configured or viewed.
Parameter Description
Interface
The IP interface on the Switch that will be connected directly to the Client.
Server IP
Enter the IP address of the DHCP/BOOTP server. Up to four server IPs can be configured per IP
Interface
51
