xStack
®
DGS-3600 Series Layer 3 Managed Gigabit Ethernet Switch
CPU Utilization
This window displays the percentage of the CPU being used, expressed as an integer percentage and calculated as a simple
average by time interval.
To view this window, click Monitoring > CPU Utilization, as shown below:
Figure 8- 6. CPU Utilization window
Click Apply to implement the configured settings. The window will automatically refresh with new updated statistics
The information is described as follows:
Parameter Description
Time Interval
Select the desired setting between 1s and 60s, where "s" stands for seconds. The default
value is one second.
Record Number
Select number of times the Switch will be polled between 20 and 200. The default value is
200.
Show/Hide
These check boxes allow the user to choose the CPU utilization over increments of Five
Secs, One Min and Five Mins. Each time increment will be displayed in the window as a
specifically colored line. Five seconds will be displayed as yellow, one minute as blue and
five minutes as pink.
418
