xStack
®
DGS-3600 Series Layer 3 Managed Gigabit Ethernet Switch
SNMP View Table
This window is used to assign views to community strings that define which MIB objects can be accessed by a remote SNMP
manager.
To view this window, click Administration > SNMP Manager > SNMP View Table, as shown below:
Figure 2- 70. SNMP View Table window
To delete an existing SNMP View Table entry, click the corresponding
button in the Delete column. To create a new entry,
click the Add button which will reveal a new window.
Figure 2- 71. SNMP View Table Configuration window
The SNMP View created with this table maps SNMP users (identified in the SNMP User Table) to the views created in the
previous window.
The following parameters can set:
Parameter Description
View Name
Type an alphanumeric string of up to 32 characters. This is used to identify the new SNMP
view being created.
Subtree OID
Type the Object Identifier (OID) Subtree for the view. The OID identifies an object tree (MIB
tree) that will be included or excluded from access by an SNMP manager.
View Type
Select Included to ensure this object is included in the list of objects that an SNMP manager
can access. Select Excluded to exclude this object from the list of objects that an SNMP
manager can access.
To implement your new settings, click Apply. To return to the SNMP View Table window, click the Show All SNMP View
Table Entries link.
66
