xStack
®
DGS-3600 Series Layer 3 Managed Gigabit Ethernet Switch
dynamically registered VLAN entries will be cleared, GVRP will be disabled. According
802.1ad, the address 01-80-c2-00-00-08 will be used for STP in the provider’s network. So the
user shall disable STP first, and then use the new address for STP state machine. The default
setting is Disabled.
Unit
Select the Switch to be configured.
From/To
A consecutive group of ports that are part of the VLAN configuration starting with the selected
port.
Role
The user can choose between UNI or NNI role.
UNI – To select a user-to-network interface which specifies that communication between the
specified user and a specified network will occur.
NNI – To select a network-to-network interface specifies that communication between two
specified networks will occur.
Missdrop
Enable or Disable C-VLAN based on SP-VLAN assignment miss drop. When enabled the
tagged packet will be dropped if the VLAN translation look up misses. When disabled the
packet will not be dropped if the VLAN translation loop up misses. If VLAN translation table
lookup misses, the packet can be either dropped or add an outer VLAN based on
MAC/SUBNET/PROTOCOL/PORT based VLAN configuration. This will make the packet as a
double tagged packet.
Note: The result will be Transparent Mode behavior.
TPID(0x1-0xffff)
The Outer TPID is used for learning and switching packets. The Outer TPID constructs and
inserts the outer tag into the packet based on the VLAN ID.
Use Inner Priority
Specify whether to use the priority in the C-VLAN tag as the priority in the S-VLAN tag. By
default, the setting is Disabled.
Click Apply to implement changes.
159
