xStack
®
DGS-3600 Series Layer 3 Managed Gigabit Ethernet Switch
Figure 4- 25. Policy Routing – Add window
Adjust the following parameters and click Apply to set the new Policy Route, which will be displayed in the Policy Routing
Settings window. Click Show All Policy Route Entries
to return to the Policy Routing Settings window.
Parameter Description
Name
Enter a name of no more than 32 alphanumeric characters that will be used to identify this policy
route.
Profile ID
Enter the Profile ID number of the Access Profile, previously created, which will be used to
identify packets as following this Policy Route. This access profile, along with the access rule,
must first be constructed before this policy route can be created.
Access ID
Enter the Access ID number of the Access Rule, previously created, which will be used to
identify packets as following this Policy Route. This access rule, along with the access profile,
must first be constructed before this policy route can be created.
Nexthop
This is the IP address of the Next Hop router that will have a direct connection to the Gateway
router connected to the Internet.
State
Use the pull-down menu to enable or disable this Policy Route.
190
