xStack
®
DGS-3600 Series Layer 3 Managed Gigabit Ethernet Switch
OSPFv3 Area Aggregation Settings
Area Aggregation allows all of the routing information that may be contained within an area to be aggregated into a summary
LSDB advertisement of just the network address and subnet mask. This allows for a reduction in the volume of LSDB
advertisement traffic as well as a reduction in the memory overhead in the Switch used to maintain routing tables. There are no
aggregation settings configured by default, so there will not be any listed the first accessing the window. To add a new OSPFv3
Area Aggregation setting, click the Add button. A new window (pictured below) appears. To change an existing configuration,
click on the corresponding Modify button for the set you want to change. The window to modify an existing configuration is the
same as the window used to add a new one.
To view the following window, click L3 Features > OSPF > OSPFv3 > OSPFv3 Area Aggregation Settings, as shown below:
Figure 4- 72. OSPFv3 Area Aggregation Table window
To search for an entry by Area ID, click the Find button.
To display all OSPFv3 area aggregation entries, click the View All button.
To remove an entry from the table, click its corresponding
under the Delete heading.
Clicking the Add button will reveal the following window to configure:
Figure 4- 73. OSPFv3 Area Aggregation Settings - Add window
To edit an entry in the OSPFv3 Area Aggregation Table window, click the Modify button.
231
