xStack
®
DGS-3600 Series Layer 3 Managed Gigabit Ethernet Switch
Figure 6- 38. CPU Interface Filtering Rule Configuration window (Packet Content Mask)
To set the Access Rule for Ethernet, adjust the following parameters and click Apply.
Parameters Description
Profile ID
This is the identifier number for this profile set.
Mode
Select Permit to specify that the packets that match the access profile are forwarded by the
Switch, according to any additional rule added (see below).
Select Deny to specify that packets that do not match the access profile are not forwarded by
the Switch and will be filtered.
Access ID
Type in a unique identifier number for this access. This value can be set from 1 to 100.
338
