xStack
®
DGS-3600 Series Layer 3 Managed Gigabit Ethernet Switch
The following window is the CPU Access Rule Table for IPv6.
Figure 6- 40. CPU Access Rule Table window (IPv6)
To create a new rule set for an access profile click the Add button. A new window is displayed. To remove a previously created
rule, click the corresponding
button. The following window is used for the CPU IP Rule configuration.
Figure 6- 41. CPU Interface Filtering Rule Configuration window (IPv6)
The following parameters may be viewed or modified:
Parameter Description
Profile ID
This is the identifier number for this profile set.
Mode
Select Permit to specify that the packets that match the access profile are forwarded by the
Switch, according to any additional rule added (see below).
Select Deny to specify that packets that match the access profile are not forwarded by the
Switch and will be filtered.
Access ID (1-100)
Type in a unique identifier number for this access. This value can be set from 1 to 100.
Type
Selected profile based on Ethernet (MAC Address), IP address, Packet Content or IPv6.
Ethernet instructs the Switch to examine the layer 2 part of each packet header.
IP instructs the Switch to examine the IP address in each frame's header.
340
