xStack
®
DGS-3600 Series Layer 3 Managed Gigabit Ethernet Switch
To configure individual JWAC port settings, click the Add button, the following window will be displayed.
Figure 7- 80. JWAC Port Settings window (Add)
To configure the settings by port, click on the corresponding Modify button, which will display the following window:
Figure 7- 81. JWAC Port Settings window (Modify)
To set the JWAC on individual ports for the Switch, complete the following fields:
Parameter Description
Unit
Choose the Unit ID of the switch in the switch stack to configure.
Port List
Lists the range of Ports that will be configured in this window.
State
This parameter specifies the state of the configured ports.
Mode
Use the drop-down menu to select the mode, choose either Port Based or Host Based.
Max Authenticating
This parameter specifies the maximum number of host process authentication attempts
411
