xStack
®
DGS-3600 Series Layer 3 Managed Gigabit Ethernet Switch
Figure 8- 26. Authenticator Statistics Detail Table window
The following fields can be viewed:
Parameter Description
Port/Port Number
The identification number assigned to the Port by the System in which the Port resides.
MAC Address
EapolFramesRX
The number of valid EAPOL frames that have been received by this Authenticator.
EapolFramesTX
The number of EAPOL frames that have been transmitted by this Authenticator.
EapolStartFramesRX
The number of EAPOL Start frames that have been received by this Authenticator.
EapolReqIdFramesTX
The number of EAP Req/Id frames that have been transmitted by this Authenticator.
EapolLogoffFramesRX
The number of EAPOL Logoff frames that have been received by this Authenticator.
EapolReqFramesTX
The number of EAP Request frames (other than Rq/Id frames) that have been
transmitted by this Authenticator.
EapolRespIdFramesRX
The number of EAP Resp/Id frames that have been received by this Authenticator.
EapolRespFramesRX
The number of valid EAP Response frames (other than Resp/Id frames) that have been
received by this Authenticator.
InvalidEapolFramesRX
The number of EAPOL frames that have been received by this Authenticator in which
the frame type is not recognized.
EapLengthErrorFramesRX
The number of EAPOL frames that have been received by this Authenticator in which
the Packet Body Length field is invalid.
LastEapolFrameVersion
The protocol version number carried in the most recently received EAPOL frame.
LastEapolFrameSource
The source MAC address carried in the most recently received EAPOL frame.
437
