xStack
®
DGS-3600 Series Layer 3 Managed Gigabit Ethernet Switch
Figure 8- 30. Authenticator Diagnostics Detail Table window
The following fields can be viewed:
Parameter Description
Port/Port Number
The identification number assigned to the Port by the System in
which the Port resides.
MAC Address
The MAC address of the Switch where the port resides.
EntersConnecting
Counts the number of times that the state machine transitions to the
CONNECTING state from any other state.
EapLogoffsWhileConnecting
Counts the number of times that the state machine transitions from
CONNECTING to DISCONNECTED as a result of receiving an
EAPOL-Logoff message.
EntersAuthenticating
Counts the number of times that the state machine transitions from
CONNECTING to AUTHENTICATING, as a result of an EAP-
Response/Identity message being received from the Supplicant.
SuccessWhileAuthenticating
Counts the number of times that the state machine transitions from
AUTHENTICATING to AUTHENTICATED, as a result of the
Backend Authentication state machine indicating successful
authentication of the Supplicant (authSuccess = TRUE).
TimeoutsWhileAuthenticating
Counts the number of times that the state machine transitions from
AUTHENTICATING to ABORTING, as a result of the Backend
Authentication state machine indicating authentication timeout
(authTimeout = TRUE).
441
