FC 300 Design Guide
How to Program
Function:
Enter the high voltage value. This analog input
scaling value should correspond to the maximum
reference value, set in par. 3-0 3.
6-12 Terminal 53 Low Current
Range:
0.0topar. 6-13mA
*
0.14 mA
Function:
Enter the low current value. This reference signal
should correspond to the minimum reference
value, set in p ar. 3-02. The value must be
set at >2 mA in order to activate the live zero
timeout function in par. 6-01.
6-13 Term inal 53 High Current
Range:
Par. 6-12 to - 20.0 mA
*
20.0 mA
Function:
Enter the value of the reference signal that
corresponds to the maximum reference
value, set in par. 3-03.
6-14 Termin al 53 Low Ref./Feedb. Value
Range:
-1000000.0 00 to par. 6-15
*
0.000 Unit
Function:
Enter the analog input sca ling value that
corresponds to the m inimum reference feedback
value set in par. 3-02.
6-15 Terminal 53 High Ref./Feedb. Value
Range:
Par. 6-14 to 1000000.000
*
1500.000 Unit
Function:
Enter the analog input sca ling value that
corresponds to the maximum reference feedback
value set in par. 3-03.
6-16 Terminal 53 Filter Time C o nstant
Range:
0.001 - 10.000 s
*
0.001s
Function:
Enter the time constant. This is a first-order
digital low pass filter time constant for suppressing
electrical noise in terminal 53. A high time constant
value improves dampening but also increases
thetimedelaythroughthefilter.
This parameter cannot be adjusted while
the motor is running.
" 6-2* Analog Input 2
Parameters for configuring the scaling and limits
for analog input 2 (terminal 54).
6-20 Terminal 5 4 Low Voltage
Range:
-10.0–par. 6-21
*
0.07 V
Function:
Enter the low voltage value. This analog input
scaling value s ho uld correspond to the minimum
reference value, set in par. 3-02. See also
the section Reference Handling.
6-21 Termin al 54 H igh Volt age
Range:
Par. 6-20 to 10.0 V
*
10.0V
Function:
Enter the high voltage value. This analog input
scaling value should correspond to the maximum
reference value, set in par. 3-03.
6-22 Term inal 54 Low Current
Range:
0.0topar. 6-23mA
*
0.14 mA
Function:
Enter the low current value. This reference signal
should correspond to the minimum reference
value, set in par. 3-02. The value must be
set at >2 mA in o rd er to activate the live zero
timeout function in p a r. 6-01.
6-23 Term inal 54 H igh Current
Range:
Par. 6-22 to - 20.0 mA
*
20.0 mA
Function:
Enter the value of the reference signa l that
corresponds to the maximum reference
value, set in par. 3-03.
6-24 Term in al 54 Low Ref./Feedb. Value
Range:
-1000000.0 00 to par. 6-25
*
0.000 Unit
*
default setting ()display text []value for use in communication via serial communication port
203
MG.33.B
6.22 - V LT is a registered Danfoss trademark
