Danfoss FC 300 Design Guide

FC 300 Design Guide
How to Program
Function:
Enter the analog input sca ling value that
corresponds to the m inimum reference feedback
value set in par. 3-02.
6-25 Terminal 54 high ref./feedb. value
Range:
Par. 6-24 to 1000000.000
*
1500.000 Unit
Function:
Enter the analog input sca ling value that
corresponds to the maximum reference feedback
value set in par. 3-03.
6-26 Terminal 54 Filter Time C o nstant
Range:
0.001 - 10.000 s
*
0.001s
Function:
Enter the time constant. This is a first-order
digital low pass filter time constant for suppressing
electrical noise in terminal 54. A high time constant
value improves dampening but also increases
the time delay through the filter.
This parameter cannot be adjusted while
the motor is running.
" 6-3* Analog Input 3 (MCB 101)
Parametergroupforconfiguringthescale
and limits for analog input 3 (X30/11) placed
on option module MCB 101.
6-30 Term. X30/11 Low Voltage
Range:
-10 - par. 6-31
*
0.07 V
Function:
Sets the analog input scaling value to correspond to
the m inimum reference value (set in par. 3-02).
6-31 Term. X30/11 High Voltage
Range:
Par. 6-31 to 10.0 V
*
10.0 V
Function:
Sets the analog input scaling value to correspond to
the m aximum reference value (set in par. 3-03).
6-34 Term. X30/11 Low Ref./Feedb. Value
Range:
1000000.000 to pa r. 6-35
*
0.000 Unit
Function:
Sets the analog input scaling value to correspond
to the minimum reference feedback value
(set in par. 3-02).
6-35 Term. X30/11 High Ref./Feedb. Value
Range:
Par. 6-34 to 1000000.000
*
1500.000 Unit
Function:
Sets the analog input scaling value to correspond
to the maximum reference feedback value
(set in par. 3-03).
6-36 Term. X30/11 Filter T ime Constant
Range:
0.001 - 10.000 s
*
0.001 s
Function:
A1
st
order digital low p ass f ilte r time constant for
suppressing electrical noise on terminal X30/11.
Par. 6-36 cannot b e changed while the
motor is running.
" 6-4* Analog Input 4 (MCB 101)
Parametergroupforconfiguringthescale
and limits for analog input 3 (X30/12) placed
on option module MCB 101.
6-40 Term. X30/12 Low Voltage
Range:
-10.0 to par. 6-41
*
0.7 V
Function:
Sets the analog input scaling value to correspond to
the minimum reference value (set in par. 3-02).
6-41 Term. X30 /1 2 High Voltage
Range:
Par. 6-41 to 10.0 V
*
10.0 V
Function:
Sets the analog input scaling value to correspond to
the m aximum reference value (set in par. 3-03).
6-44 Term. X3 0/ 12 Low Ref./Feedb. Value
Range:
-1000000.0 00 to par. 6-45
*
0.000 Unit
*
default setting ()display text []value for use in communication via serial communication port
204
MG.33.B
6.22 - V LT is a registered Danfoss trademark

Danfoss FC 300 Specifications

General

Enclosure	IP20
Approvals	cUL, UL, CE
EMC filter	Built-in
Communication Options	CANopen, PROFIBUS DP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Output Voltage	0-100% of supply voltage
