FC 300 Design Guide
How to Program
can never be higher than the corresponding setting
in par. 6-62 if value is below 100%.
This parameter is active when option module MCB
101 is mounted in the adjustable freq u ency drive.
6-62 Term. X30/8 Output M ax Scale
Range:
0.00 - 200%
*
100%
Function:
Scales the m aximum outp ut of the selected analog
signal on terminal X30/ 8. Scale the value to the
desired maximum value of the current signal output.
Scale the output to give a lower current than 20 mA
atfullscaleor20mAatanoutputbelow100%of
the maximum signal value. If 20 mA is the desire d
output current at a value between 0 - 100% of the
full-scale output, program the percentage value
in the parameter, i.e ., 50% = 20 mA. If a current
between 4 and 20 MA is desired at maximum output
(100%), calculate the percentage value as follows:
*
default setting ()display text []value for use in communication via serial communication port
207
MG.33.B
6.22 - V LT is a registered Danfoss trademark
