FC 300 Design Guide
How to Program
function. Note the following configuration
required in order to change the set-up after
atime-out: SetPar. 0-10Active set-up to
Multi set-up [9], and select the relevant link
in par. 0-12 This Set-up Linked To.
8-05 End-of-Timeout Function
Option:
*
Hold set-up [0]
Resume set-up [1]
Function:
Select the action after receiving a valid control
word following a time-out. This parameter is active
only when par. 8-04 is set to Set-up 1-4.
Hold: The frequency converter retains the set-up
selected in p ar. 8-04 and displays a warning,
until par. 8-06 toggles. Then the frequency
converter resumes its original set-up.
Resume: The frequency converter resumes the
set-up active prior to the time-out.
8-06 Reset Control Word Timeout
Option:
*
Do not reset [0]
Do reset [1]
Function:
Select Do reset [1] to return the frequency converter
to the original set-up following a control word
time-out. When the value is set to Do reset [1], th
e
frequency converter performs the reset and then
immediately reverts to the Do not reset [0] setting.
Select Do not reset [0] to retain the set-up
specified in par. 8-04, Select setup 1-4 following
a control word time-out.
This parameter is active only when Hold
set-up [0] has been selected in par. 8-05
End-of-Time-out Function.
8-07 Diagnosis Trigger
Option:
*
Disable [0]
Trigger on alarm s [1]
Trigger alarms/warn. [2]
Function:
This parameter enables and controls the drive
diagnosis function and perm
its e xpansion of the
diagnosis d ata to 24 byte. It relates o nly to Profibus.
- Disable [0]: Do not send extended
diagnosis data even if they appear in the
adjustable frequency drive.
- Trigger on alarms [1]: Send extended diagnosis
data when one or more alarms appear in
alarm par. 16-90 or 9-53.
- Trigger alarms/w a rn.[2]: Send extende d
diagnosis data if one or more alarms or
warnings appear in alarm par. 16-90, 9-53,
or warning par. 16-92.
The content of the extended diagnosis
frame is as follows:
Byte Content Description
0-5 Standard DP
Diagnose Data
Standard DP Diagnose Data
6 PDU length xx Header of extended diagnostic
data
7 Status type =
0x81
Header of extended diagnostic
data
8 Slot = 0 Header of extended diagnostic
data
9 Status info = 0 Heade r of extended diagnostic
data
10 - 13 VLT par. 16-92 VLT warning word
14 - 17 VLT par. 16-03 VLT status word
18 - 21 VLT par. 16-90 VLT alarm word
22 - 23 VLT par. 9-53 Communication warning word
(Profibus)
Enabling diagnosis may cau se increased bus
traffic. Diagnosis functions are not supported by
all serial communication bus types.
" 8-1* Ctrl. Word Settings
Parameters for configuring the option
control w ord profile.
8-10 Control Word Profile
Option:
*
FC profile [0]
PROFIdrive profile [ 1]
ODV
A
[5]
CANopen DSP 402 [7]
Function:
Sel
ect the interpretation of the control and
status words corresponding to the installed serial
communication bus. Only the selections valid
*
default setting ()display text []value for use in communication via serial communication port
212
MG.33.B
6.22 - V LT is a registered Danfoss trademark
