for the serial communication bus installed in slot
A will be visible in the LCP display.
ForguidelinesforselectingFC profile [0] and
PROFIdrive profile [1], please refer to the Serial
communication via RS 485 Interface section
in the How to Program chapter.
For additional guidelines in the selection of
PROFIdrive profile [1], ODVA [5] and CANopen
DSP 402 [7], please refer to the Instruction Manual
for the installed serial communication bus.
8-13 Configurable Status Word STW
Option:
Bit 12 [12]
Bit 13 [13]
Bit 14 [14]
Bit 15 [15]
Function:
This parameter enables configuration of bit
12–15inthestatusword.
Profile Default [1]: The function on
the bit corresponds to the profile default
selected in par. 8-10.
Alarm 68 Only [2]: The bit is only set
in case of an Ala rm 68.
Trip except Alarm 68 [3]: The bit is set in case of
a trip, except if the tr ip is executed by an Alarm 68.
T37 DI status [16]: The b it indicates the
status of terminal 37.
“0” indicates T37 is low (safe stop)
“1” indicates T37 is high (normal)
" 8-3* FC Por t Settings
Parameters for configuring the FC Port.
8-30 Protocol
Option:
*
FC [0]
FC MC [1]
Function:
Select the protocol for the FC (standard ) port.
8-31 Address
Range:
1-126
*
1
Function:
Enter the ad dre ss for the FC (standard) port.
Va lid range: 1 - 126.
8-32 FC Port Baud Rate
Option:
2400 Baud [0]
4800 Baud [1]
*
9600 Baud [2]
19200 Baud [3]
38400 Baud [4]
115200 Baud [7]
Function:
Baud rate selection for the F C ( standard) port.
8-35 Minimum Response Delay
Range:
1-500ms
*
10ms
Function:
Specify the minimum delay time between receiving
a request and transmitting a response. This is used
for overcoming modem turnaround delays.
8-36 Max Response Delay
Range:
1 - 10000 ms
*
5000ms
Function:
Specify the maximum permissible delay time
between transmitting a request and receiving
a r esponse. Exceed ing this delay time will
cause control word time-out.
8-37 Max Inter-Char Delay
Range:
0-30ms
*
25ms
Function:
Specify the maximum permissible time interval
between receipt of two bytes. This parameter
activates tim e-out if transmission is interrupted.
This parameter is active only when par. 8-30
is set to FC MC [1] protocol.
" 8-5* Digital/Bus
Parameters for configuring the control word
Digital/Bus merging.
8-50 Coastin g Se lect
Option:
Digital input [0]
Bus [1]
*
default setting ()display text []value for use in communication via serial communication port
213
MG.33.B
6.22 - V LT is a registered Danfoss trademark
