FC 300 Design Guide
How to Program
Logic AND [2]
*
Logic OR [3]
Function:
Select control of the coasting function via the
terminals (digital input) and/or via the bus.
NOTE
This parameter is active only when
par. 8-01 Control Site is set to [0]
Digital and control word.
8-51 Quick Stop Select
Option:
Digital input [0]
Bus [1]
Logic AND [2]
*
Logic OR [3]
Function:
Select control of the Quick Stop function via the
terminals (digital input) and/or via the bus.
NOTE
This parameter is active only when
par. 8-01 Control Site is set to [0]
Digital and control word.
8-52 DC Brake Select
Option:
Digital input [0]
Bus [1]
Logic AND [2]
*
Logic OR [3]
Function:
Select control of the DC brake via the termin
als
(digital input) and/or via the field bus.
NOTE
This parameter is active only when
par. 8-01 Control Site is set to [0]
Digital and control word.
8-53 Start Select
Option:
Digital input [0]
Bus [1]
Logic AND [2]
*
Logic OR [3]
Function:
Select control of the frequency converter
start function via the terminals (digital inp ut)
and/or via the fieldbus.
Select Bus [1], t o activate the Start command via
the serial communicatio n port or fieldbus option.
Select Logic AND [2] to activate the Start command
via the fieldbus/serial communication port, AND
additionally via one o f the d igital inputs.
Select Logic OR [3] to activate the Start comma nd
via the fieldbus/s erial communication port OR
via one of the digital inputs .
NOTE
This parameter is active only when
par. 8-01 Control Site is set to [0]
Digital and control w ord.
8-54 Reverse S elect
Option:
Digital input [0]
Bus [1]
Logic AND [2]
*
Logic OR [3]
Function:
Select control of the frequency converter
reverse function via the terminals (digital
input) and/or via the fieldbus.
Select Bus [1 ], to activate the Reverse command via
the serial communicatio n port or fieldbus option.
Select Logic AND [2] to activate the Reverse
command via the fieldbus/serial communication
port, A ND additionally via one of the digital inputs.
Select Logic OR [3] to activate the Reverse
command via the fieldbus/serial communication
port OR via one of the digital inputs.
NOTE
This parameter is active only when
par. 8-01 Control Site is set to [0]
Digital and control w ord.
8-55 Set-up Select
Option:
Digital input [0]
Bus [1]
Logic AND [2]
*
Logic OR [3]
*
default setting ()display text []value for use in communication via serial communication port
214
MG.33.B
6.22 - V LT is a registered Danfoss trademark
