FC 300 Design Guide
How to Program
Function:
Select control of the frequency converter
set-up selectio n via the terminals (digital
input) and /or via the fieldbus.
Select Bus [1], to activate the set-up selection via
the serial communication port or fieldbus option.
Select Logic AND [2] to activate the set-up selection
via the fieldbus/serial communication port, AND
additionally via one of the digital inputs.
Select Logic OR [3] to activate the set-up selection
via the fieldbus/serial communication port OR
via one of the digital inputs.
NOTE
This parameter is active only when
par. 8-01 Control Site is set to [0]
Digital and control word.
8-56 Preset Reference Select
Option:
Digital input [0]
Bus [1]
Logic AND [2]
*
Logic OR [3]
Function:
Select contro l of the frequency converter Preset
Reference selection via the terminals (digital
input) and /or via the fieldbus.
Select Bus [1], to activate the Preset Reference
selection v ia the serial communication port
or fieldbus option.
Select Logic AND [2] to activate the Preset Reference
selection via the field bus/se rial communication port,
AND add itionally via one of the digital inpu
ts.
Select Logic OR [3] to activate the Preset Reference
selection via the fieldbus/serial communication
port OR via one of the digital inputs.
NOTE
This parameter is active only when
par. 8-01 Control Site is set to [0]
Digital and control word.
" 8-9* Bus Jog
Parameters for configuring the Bus Jog.
8-90 Bus Jog 1 Speed
Range:
0-par. 4-13RPM
*
100RPM
Function:
Enter the jog speed. This i s a fixed jog speed
activated via the serial port or fieldbus option.
8-91 Bus Jog 2 Speed
Range:
0-par. 4-13RPM
*
200RPM
Function:
Enter the jog speed. This i s a fixed jog speed
activated via the serial port or fieldbus option.
*
default setting ()display text []value for use in communication via serial communication port
215
MG.33.B
6.22 - V LT is a registered Danfoss trademark
