FC 300 Design Guide
How to Program
Function:
Enter the station address in this parameter or
alternatively in the hardware switch. In order
to adjust the station addres s in par. 9-18, the
hardware s witch must be set to 126 or 127 (i.e.
all switches set to ‘on’). Otherwise this parameter
will disp lay the actual setting of the switch.
9-22 Telegram S elect ion
Option:
Standard telegram 1 [1]
PPO 1 [101]
PPO 2 [102]
PPO 3 [103]
PPO 4 [104]
PPO 5 [105]
PPO 6 [106]
PPO 7 [107]
*
PPO 8 [108]
Function:
Select a s tandard Profibus teleg ram configu ration
for the frequency converter, as an alternative
to using the freely configurable te leg rams
in par. 9-15 and 9-16.
9-23 Parameters for Signa ls
Array [1000]
Option:
None
3-02 Minimum Reference
3-03 Maximum Reference
3-12 Catch Up/Slow Down Value
3-41Ramp1RampUpTime
3-42 Ramp 1 Ramp Down Time
3-51Ramp2RampUpTime
3-52 Ramp 2 Ramp Down Time
3-80 Jog Ramp Time
3-81 Quick Stop Ramp Rime
4-11 Motor S peed Low Limit
4-13 Motor Speed High Limit
4-16 Torque Limit Motor Mode
4-17 Torque Limit Generator Mode
8-90 Bus Jog 1 Speed
8-91 Bus Jog 2 Speed
16-00 Control Word
16-01 Reference [Unit]
16-02 Reference %
16-03 Status Word
16-05 Main Actual Value [%]
16-10 Power [kW]
16-11 Power [hp]
16-12 Mo tor Voltage
16-13 Frequency
16-14 Motor Current
16-16 Torque
16-17 Speed [RPM]
16-18 Motor T hermal
16-19 KTY Sensor Temperature
16-20 Phase Angle
16-30 DC Link Voltage
16-32 Brake Energy / s
16-33 Brake E nerg y / 2 Min
16-34 Heatsink Temp.
16-35 Inverter Thermal
16-38 SL Controller S tate
16-39 Controlca rd Temp.
16-50 External Reference
16-51 Pulse Reference
16-52 Feedback [Unit]
16-53 Digi Pot Reference
16-60 Digital Input
16-61 Terminal 53 Switch Sett ing
16-62 Analog Input 53
16-63 Terminal 53 Switch Sett ing
16-64 Analog Input 54
16-65 Analog Output 42 [mA ]
16-66 Digital Output [bin]
16-67 Freq. Input #29 [Hz]
16-68 Freq. Input #33 [Hz]
16-69 Pulse Output #27 [Hz]
16-70 Pulse Output #29 [Hz]
16-80 Fieldbus CTW 1
16-82 Fieldbus REF 1
16-84 Comm Option STW
16-85 FC Port CTW 1
16-90 Alarm Word
16-91 Alarm Word 2
16-92 Warning Word
16-93 Warning Word 2
16-94 Extended Status Word
16-95 Extended S
tatus Word 2
Function:
This pa rameter contains a list of signals available
for selection i
npar. 9-15and9-16.
*
default setting ()display text []value for use in communication via serial communication port
