FC 300 Design Guide
How to Program
9-27 Parameter Edit
Option:
Disabled [0]
*
Enabled [1]
Function:
Parameters can be edited via Profibus , the
standard RS485 interface, or the LCP.
Select Disabled [0] to disable editing via Profibus.
9-28 Process Control
Option:
Disable [0]
*
Enable cyclic master [1]
Function:
Process control (setting of Control Word, speed
reference, and process data) is possible via
either Profibus or standard fieldbus but n ot both
simultaneously. Local control is always p ossib le
via the LCP. Control via process control is possible
via either terminals or fieldbus depending on
the settings in par. 8-50 t o 8-56.
Select Disable [0] to disable process control via
Profibus, and enable process control via standard
fieldbus or Profibus Master class 2.
Select Enable cyclic master [1] to enable
process control via Profibus Master Class 1, and
disable process control via standard fieldbus
or Profibus M aster class 2.
9-53 Profibus Warning Word
Option:
Bit: Meaning:
0 Connection with DP master is not
1 Timeout action active
2 FDL (Field-bus Data link Layer) is not ok
3 Clear data command received
4 Actual value is not updated
5 baud rate search
6 PROFIBUS ASIC is not transmitting
7 Initializing of PROFIBUS is not ok
8 drive is tripped
9 internal CAN error
10 wrong ID sent by PLC
11 Internal error occurred
12 not configured
13 clear command received
14 warning 34 active
Function:
This parameter displays Profibus communication
warnings. Please re f er to the Profi bus Operating
Instructions for further information.
9-63 Actual Baud Rate
Option:
Read-only
9.6 kbit/s [0]
19.2 kbit/s [1]
93.75 kbit/s [2]
187.5 kbit/s [3]
500 kbit/s [4]
1500 kbit/s [6]
3000 kbit/s [7]
6000 kbit/s [8]
12000 kbit/s [9]
31.25 kbit/s [10]
45.45 kbit/s [11]
No baud rate found [255]
Function:
This parameter displays the actual Profibus
baud rate. The Profibus Master automatically
sets the baud rate.
*
default setting ()display text []value for use in communication via serial communication port
218
MG.33.B
6.22 - V LT is a registered Danfoss trademark
