FC 300 Design Guide
How to Program
16-82FieldbusREF1(Fixed)
3-02 Minimum Reference
3-03 Maximum Reference
3-12 Catch up/slow-down value
3-41 Ramp 1 Ramp-up Time
3-42 Ramp 1 Ramp-down Time
3-51 Ramp 2 Ramp-up Time
3-52 Ramp 2 Ramp-down Time
3-80 Jog Ramp Time
3-81 Quick Stop Ramp Time
4-11 Motor Speed Low Lim it (RPM)
4-13 Motor Spe ed High Limit (RPM)
4-16 Torque Limit Motor Mode
4-17 Torque Limit Generator Mode
8-90 Bus Jog 1 Speed
8-91 Bus Jog 2 Speed
Function:
Select the process write data for I/O Asse mbly
Instances 101/151. Elements [2] and [3] of
this array can b e selected. Elements [0] and
[1] of the array are fixed.
10-12 Process Data Config Read
Option:
*
None
16-03 Status Word (Fixed)
16-05 Main Actual Value [%] (Fixed)
16-00 Control Word
16-01 Reference [Unit]
16-02 Reference %
16-04 Main Actual Value [Unit]
16-91 Alarm Word 2
16-92 Warning Word
16-90 Alarm Word
16-93 Warning Word 2
16-94 Ext. Sta tus Word
16-95 Ext. Status Word 2
16-10 Power [kW]
16-11 Power [hp]
16-12 Motor voltage
16-13 Frequency
16-14 Motor Current
16-16 Torque
16-17 Speed [RP M]
16-18 Motor Therma
l
16-19 KTY Sensor Temperature
16-20 Phase Angle
16-30 DC Link Vo
ltage
16-32 Brake Energy /s
16-33 Brake Energy /2 min
16-34 Heatsink Temp.
16-35 Inverter Thermal
16-38 SL Controller S tate
16-39 Control Car d Temp.
16-50 External Reference
16-51 Pulse Reference
16-52 Feedback [Unit]
16-53 Digi Pot Reference
16-60 Digital Input
16-61 Terminal 53 Switch Sett ing
16-62 Analog Input 53
16-63 Terminal 54 Switch Sett ing
16-64 Analog Input 54
16-65 Analog Output 42 [mA ]
16-66 Digital Output [bin]
16-67 Freq. Input #29 [Hz]
16-68 Freq. Input #33 [Hz]
16-69 Pulse Output #27 [Hz]
16-70 Pulse Output #29 [Hz]
16-84 Comm Option St atus
16-85 FC Port CTW 1
16-09 Custom Readout
Function:
Select the process read data for I/O Assembly
Instances 101/151. Elem ents [2] and [3] of
this array can b e selected. E lem ents [0] and
[1] of the array are fixed.
10-13 Warning Parameter
Range:
0-63
*
63
Function:
View a D eviceNet-specific Warning word. One
bit is assigned to every warning. Please
refer to the DeviceNet Operating Instructions
(MG.33.DX.YY) for further information.
*
default setting ()display text []value for use in communication via serial communication port
222
MG.33.B
6.22 - V LT is a registered Danfoss trademark
