Danfoss FC 300 Design Guide

FC 300 Design Guide
How to Program
16-53 Digi Pot Reference
Range:
0.0 - 0.0
*
0.0
Function:
View the contr ibution of the Digita l Potentiometer
to the a ctual referen ce.
" 16-6* Inputs and Outputs
Parameters for reporting the digital a n d
analog IO ports.
16-60 Digital Input
Range:
0-63
*
0
Function:
View the signal states from the active digital inputs.
Input 18 corre sponds to the bit at the far left. ‘0’
= n o signal, ‘1’ = connected signal.
Bit 0 Digital input term. 33
Bit 1 Digital input term. 32
Bit 2 Digital input term. 29
Bit 3 Digital input term. 27
Bit 4 Digital input term. 19
Bit 5 Digital input term. 18
Bit 6 Digital input term. 37
Bit 7 Digital input GP I/O term. X30/2
Bit 8 Digital input GP I/O term. X30/3
Bit 9 Digital input GP I/O term. X30/4
Bit 10- 63 Reserved for future terminals
16-61 Terminal53SwitchSetting
Option:
*
Current [0]
Voltage [1]
Function:
View the setting of input terminal 5 3.
Current=0;Voltage=1.
16-62 Ana log Input 53
Range:
0.000 - 0.000
*
0.000
Function:
View the actual value at input
53 either as a
reference or a protection value.
16-63 Terminal54SwitchSetting
Option:
*
Current [0]
Voltage [1]
Function:
View the setting of input terminal 54.
Current=0;Voltage=1.
16-64 Analog Input 54
Range:
0.000 - 0.000
*
0.000
Function:
View the actual value at input 54 either as a
reference or a protection value.
16-65 Analog Output 42 [mA]
Range:
0.000 - 0.000
*
0.000
Function:
View the actual value at output 42 in mA. T he value
shown re flects the selection in par. 06-50.
16-66 Digital Output [bin]
Range:
0-3
*
0
Function:
View the binary value of all digital outputs.
16-67 Freq. Input #29 [Hz]
Range:
0-0
*
0
Function:
View the actual fre quency rate on terminal 29.
This parameter is available for FC 302 only.
16-68 Freq. Input #33 [Hz]
Range:
0-0
*
0
Function:
View the actual value of the frequency applied
at ter minal 29 as an impulse input.
*
default setting ()display text []value for use in communication via serial communication port
248
MG.33.B
6.22 - V LT is a registered Danfoss trademark
