FC 300 Design Guide
Troubleshooting
Description of Alarm Word, Warning Word, and extended Status Word
Alarm Word Extended Status Word
Bit Hex Dec AlarmWord WarningWord ExtendedStatusWord
0 00000001 1 Brake Check Brake Check Ramping
1 00000002 2 Pwr. Card Temp Pwr. Card Temp AMA Running
2 00000004 4 Ground Fault Ground Fault Start CW/CCW
3 00000008 8 Ctrl.Card Temp Ctrl.Card Temp Slow-down
4 00000010 16 Ctrl. Word TO Ctrl. Word TO Catch up
5 00000020 32 Overcurrent Overcurrent Feedback High
6 00000040 64 Torque Limit Torque Limit Feedback Low
7 00000080 128 Thrmstr overld Thrmstr overld Output Current High
8 00000100 256 Motor ETR Over Motor ETR Over Output Current Low
9 00000200 512 Inverter Overld. Inverter Overld. Output Freq High
10 00000400 1024 DC undervolt DC undervolt Output Freq Low
11 00000800 2048 DC overvolt DC overvolt Brake Check OK
12 00001000 4096 Short Circuit DC Voltage Low Braking Max
13 00002000 8192 Soft-charge Fault DC Voltage High Braking
14 00004000 16384 Line ph. L oss Line ph. Loss Out of Speed Range
15 00008000 32768 AMA Not OK No Motor OVC A ctive
16 00010000 65536 Live Zero Error Live Zero Error
17 00020000 131072 Internal Fault 10 V Low
18 00040000 262144 Brake Overload Brake Overload
19 00080000 524288 U phase Loss Brake Resistor
20 00100000 1048576 V phase Loss Brake IGBT
21 00200000 2097152 W phase Loss Speed Limit
22 00400000 4194304 Ser. com. bus
fault
Ser. com. bus fault
23 00800000 8388608 24 V Supply Low 24 V Supply Low
24 01000000 16777216 Line Failure Line Failure
25 02000000 33554432 1.8 V Supply Low Current Limit
26 04000000 67108864 Brake Resistor Low Temp
27 08000000 134217728 Brake IGBT Voltage Limit
28 10000000 268435456 Option Change Unused
29 20000000 536870912 Drive Initialized Unused
31 80000000 2147483648 Mech. brake low Extended Status Word
Thealarmwords,warningwordsandextendedstatuswordscanbereadoutviaserialbusor
optional ser. com. bus for diagnos is. See also par. 16-90, 16-92, and 16-94.
WARNING 1
10 V low:
The10Vvoltagefromterminal50onthe
control card is below 10 V.
Remove some of the load from terminal 50,
as the 10 V supply is overloaded. Max. 15
mA or minimum 590 Ω.
WARNING/ALARM 2
Live zero error:
The signal on terminal 53 or 54 is less than
50% of the value set in par. 6-10, 6-12,
6-20, or 6-22 respectively.
WARNING/ALARM 3
No motor:
No motor has been connecte d to the output of
the adjustable freque n cy drive.
WARNING/ALARM 4
Mains phase loss:
A phase is missing on the supply side, or the
line voltage imbalance is too high.
This message also appears in case of a fault in the
input rectifier on the adjustable frequency drive.
Check the supply voltage and supply currents
to the adjustable frequency drive.
299
MG.33.B6.22 - VLT is a registered Danfoss trademark
