Danfoss FC 300 Design Guide

FC 300 Design Guide
How to Order
" Ordering Numbers: Harmonic Filters
Harmonic filters are use d to reduce line harmonics.
• AHF 010: 10% current distortion
• AHF 005: 5% current distortion
380-415V,50Hz
Danfoss ordering numberI
AHF,N
Typical Motor Used [kW]
AHF 005 AHF 010
FC 301/FC 302
10 A 4, 5.5 175G6600 175G6622 P4K0, P5K5
19 A 7.5 175G6601 175G6623 P7K5
46 A 11 175G6602 175G6624 P11K
35 A 15, 18.5 175G6603 175G6625 P15K, P18K
43 A 22 175G6604 175G6626 P22K
440-480V,60Hz
Danfoss ordering numberI
AHF,N
Typ ical M otor U sed
[HP]
AHF 005 AHF 010
FC 301/FC 302
19 A 10, 15 175G6612 175G6634 P7K5
26 A 20 175G6613 175G6635 P15K
35 A 25, 30 175G6614 175G6636 P18K, P22K
500V,50Hz
Danfoss ordering numberI
AHF,N
Typ ical M otor U sed
[kW]
AHF 005 AHF 010
FC 301/FC 302
10 A 4, 5.5 175G6644 175G6656 P4K0, P5K5
19 A 7.5, 11 175G6645 175G6634 P7K5, P11K
26 A 15, 18.5 175G6646 175G6635 P15K, P18K
35 A 22 175G6647 175G6636 P22K
Matching the adjustable frequency drive and filter is pre-calculat
ed base d on 400 V/480 V
and on a typical motor load (4-pole) and 160% torque.
" Ordering Numbers: LC Filter Modules,
200-240 VAC
Mains supply 3 x 200-240 V
FC 301/ FC 302 LC filter enclosure
Rated current
at 200 V
Max. torque
at CT/VT
Max. output
frequency
Ordering no.
PK25 - P1K5 Bookstyle IP 20 7.8 A 160% 120 Hz 175Z0825
P2K2 - P3K 7 Bookstyle IP 20 15.2 A 160% 120 Hz 175Z0826
PK25 - P3K7
Compact IP 20 15.2 A 160% 120 Hz 175Z0832
90
MG.33.B6.22 - VLT is a registered Danfoss trademark

Danfoss FC 300 Specifications

General

Enclosure	IP20
Approvals	cUL, UL, CE
EMC filter	Built-in
Communication Options	CANopen, PROFIBUS DP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Output Voltage	0-100% of supply voltage
