Danfoss FC 300 Design Guide

FC 300 Design Guide
How to Order
NOTE
When using LC filters, the switching frequency must be minimum 4.5 kHz (see par. 14-01).
" Ordering Numbers: LC Filter Modules,
380-500 VAC
Mains supply 3 x 380 - 500 V
FC 301/ FC 302
LC filter
enclosure
Rated current at
400/500 V
Max. torque
at CT/VT
Max. output
frequency
Ordering
no.
PK37-P3K0 Bookstyle IP 20 7.2 A / 6.3 A 160% 120 Hz 175Z0825
P4K0-P7K5 Bookstyle IP 20 16 A / 14.5 A 160% 120 Hz 175Z0826
PK37-P7K5
Compact IP 20 16 A / 14.5 A 160% 120 Hz 175Z0832
LC filters for FC 300, 525 - 600 V, please contact Danfoss.
NOTE
When using LC filters, the switching frequency must be minimum 4.5 kHz (see par. 14-01).
91
MG.33.B6.22 - VLT is a registered Danfoss trademark

Danfoss FC 300 Specifications

General

Enclosure	IP20
Approvals	cUL, UL, CE
EMC filter	Built-in
Communication Options	CANopen, PROFIBUS DP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Output Voltage	0-100% of supply voltage
