Design Guide | iC7 Series Liquid-cooled System Modules
¢ Modulator type 2
Table 74: Power Loss for INU Modules without Options, Modulator Type 2
System
module, 2
kHz switching
frequency
System
module, 3
kHz switching
frequency
System
module, 4
kHz switching
frequency
System
module, 6
kHz switching
frequency
+AKF
X
(1)(1)
Model code Frame Rated
curre
nt
I
L(1/5)
[A]
Power
loss to
liquid
[kW]
Power
loss
to air
[kW]
Power
loss to
liquid
[kW]
Power
loss
to air
[kW]
Power
loss to
liquid
[kW]
Power
loss
to air
[kW]
Power
loss to
liquid
[kW]
Power
loss
to air
[kW]
Power
loss
to air
[kW]
iC7-60SLIN07-170AE
00F_
IM10L 170 1.00 0.01 1.20 0.01 1.47 0.01 1.83 0.02 0.01
iC7-60SLIN07-208AE
00F_
IM10L 208 1.25 0.01 1.49 0.02 1.83 0.02 2.27 0.02 0.02
iC7-60SLIN07-261AE
00F_
IM10L 261 1.68 0.02 1.95 0.02 2.37 0.02 2.99 0.03 0.02
iC7-60SLIN07-325AE
00F_
IM10L 325 2.21 0.02 2.57 0.03 3.15 0.03 - - 0.04
iC7-60SLIN07-365AE
00F_
IM10L 365 2.68 0.03 3.00 0.03 3.93 0.04 - - 0.04
iC7-60SLIN07-416AE
00F_
IM10L 416 3.13 0.03 3.60 0.04 - - - - 0.05
iC7-60SLIN07-465AE
00F_
IM12L 465 2.91 0.03 3.40 0.03 4.27 0.04 5.15 0.05 0.03
iC7-60SLIN07-525AE
00F_
IM12L 525 3.36 0.03 3.93 0.04 4.93 0.05 5.97 0.06 0.04
iC7-60SLIN07-590AE
00F_
IM12L 590 3.97 0.04 4.54 0.05 5.82 0.06 6.94 0.07 0.06
iC7-60SLIN07-650AE
00F_
IM12L 650 4.43 0.04 5.14 0.05 6.50 0.06 - - 0.07
iC7-60SLIN07-730AE
00F_
IM12L 730 5.37 0.05 6.00 0.06 7.87 0.08 - - 0.08
iC7-60SLIN07-820AE
00F_
IM12L 820 6.24 0.06 7.05 0.07 - - - - 0.11
iC7-60SLIN07-945AE
00F_
2xIM12L 945 6.35 0.06 6.93 0.07 9.31 0.09 11.40 0.11 0.05
iC7-60SLIN07-1060E
00F_
2xIM12L 1060 6.73 0.07 7.95 0.08 9.88 0.10 11.95 0.12 0.08
iC7-60SLIN07-1230E
00F_
2xIM12L 1230 8.23 0.08 9.57 0.10 12.07 0.12 - - 0.11
Danfoss Drives Oy © 2024.03 AJ475942178716en-000101 / 172K2848A | 205
