Table 81: Technical Data (continued)
Technical item or function Technical data
Temperature of coolant -10…+45 °C (14...113°F) at I
N
(nominal)
Except -10…+38 °C (14...100°F) at I
N
(nominal) for:
• AFE and GC, voltage class 07, current ratings 760 A,
1500 A, 2250 A, 2940 A, 3600 A, 4320 A, 5040 A, 5750 A
• DC/DC converter, voltage class 07, current ratings
1200 A, 2400 A, 3600 A
Temperature rise during circulation:
• 7 °C (13 °F) for INU
• 10 °C (18 °F) for AFE/GC
• 5 °C (9 °F) for DC/DC converter
Glycol to be used in coolant below 0 °C (32 °F). Freezing
not allowed.
Pressure limits Recommended default pressure: 100–150 kPa
(2)(2)
Maximum operating pressure (= Design pressure):
500 kPa
Maximum test pressure: 750 kPa
Pressure drop 50–100 kPa at rated volumetric flow
Allowed coolants Demineralized water or pure water with the quality spec-
ified in 6.3.2 Purified Water as Coolant.
Ethylene glycol
• DOWCAL 100
• Clariant Antifrogen N
Propylene glycol
• DOWCAL 200
• Clariant Antifrogen L
Liquid cooling
Heat sink material Aluminum
1) Measured at a distance of 1 m (3.3 ft), the product in a reference cabinet with the doors closed.
2) The default pressure is the static state pressure without operating the cooling pump. Cooling pump operation increases the pressure typically 100–200kPa. Do not exceed the
maximum operating pressure in any situation.
